MIC-713S-OX
MIC-713S-OX
Advantech
AI Solution Kit Based on NVIDIA® Jetson Orin™
AI Solution Kit Based on NVIDIA® Jetson Orin™.
Key Features:
- Open-frame solution kit design
- Embedded with NVIDIA® Jetson Orin™ NX up to 100 TOPS
- Supports 5 x GbE, 6 x USB 3.2 Gen 2
- Supports 1 x mPCIe, 1 x M.2 3052, 1 x M.2 2280
- Supports Allxon 24/7 remote monitoring and OTA deployment
Contact us for Lead Time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| CPU |
16GB: 8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU (2MB L2 + 4MB L3) |
| GPU | 1024-core NVIDIA Ampere GPU with 32 Tensor Cores |
| NVIDIA® CPU/GPU | NVIDIA® Jetson Orin™ |
| I/O | 4-ch DI, 4-ch DO |
| Memory |
16GB: 16GB LPDDR5 |
| CAN | 1 x CANBus |
| USB | External: 6 x USB 3.2 Gen 2 |
| Serial Ports | 2 x RS-232/422/485 (On-board pin header) |
| OTG USB | 1 x Micro USB |
| Mini PCIe | 1 x mPCIe (Signal: PCIe + USB 2.0) |
| SIM | 2 x Nano SIM slots |
| Expansion M.2 | 1 x M.2 3052 (Signal: USB) |
| GMSL (Optional) | 1 x MIPI connector for GMSL video capture card |
| Storage M.2 | 1 x M.2 2280 (Signal: PCIe x1, Gen 4) |
| Display | HDMI (Max. resolution 3840x2160 @ 60Hz) |
| Ethernet | 5 x 10/100/1000 Mbps |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
