MM1-0212SSM
MM1-0212SSM
Marki Microwave
GaAs MMIC Double Balanced Mixer
The MM1-0212SSM is a highly linear GaAs MMIC double balanced mixer. MM1-0212SSM is a low frequency, high linearity S band mixer that works well as both an up and down converter through X band. This mixer offers low conversion loss and high LO to RF isolations at the nominal LO drive.
The sister MM1- 0212HSM and MM1-0212LSM are recommended for applications which need LO operation at lower powers.
The MM1-0212SSM is available in a 4X4 mm QFN package. Evaluation boards are available.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Download The Marki Microwave Product Brochure
View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.
| Attribute | Value |
|---|---|
| Key Features |
|
| Applications |
|
| IF (GHz) | 0 to 3 |
| LO Drive Min (dBm) | +17 to +23 |
| Conversion Loss (dB) | 9 |
| Isolations L-R (dB) | 52 |
| RF/LO (GHz) Low | |
| RF/LO (GHz) High | |
| IIP3 (dBm) | +28 |
| Product Type | MMIC/Microlithic Surface Mounts |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
