MMD-1030HSM
MMD-1030HSM
Marki Microwave
GaAs MMIC Doubler
The MMD-1030HSM is a passive double balanced MMIC doubler covering 10 to 30 GHz on the output. It features excellent conversion loss, superior isolations and harmonic suppressions across a broad bandwidth, in a small form factor.
The MMD-1030HSMSM is available in a lead-free, RoHS compliant QFN surface mount package and is compatible with standard leaded and lead-free PCB reflow soldering processes. The MMD-1030HSM is a superior alternative to Marki Microwave carrier and packaged doublers.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Download The Marki Microwave Product Brochure
View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.
| Attribute | Value |
|---|---|
| RoHS | Y |
| Key Features |
|
| Conversion Loss (dB) | 12 |
| Minimum Input (GHz) | 5 |
| Maximum Input (GHz) | 15 |
| Minimum Output (GHz) | 10 |
| Suppression F (dBc) | 34 |
| Suppression 3F (dBc) | 46 |
| Maximum Output (GHz) | 30 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
