Introducing Innovative Power Products New IPP-7181 90 Degree Hybrid Coupler

Introducing Innovative Power Products New IPP-7181 90 Degree Hybrid Coupler

The new IPP-7181 covers 80 – 1000 MHz with an impressive power handling of 250W CW and is ideal for radio communications, broadcasting, radar, military, and medical applications.

Innovative Power Products IPP-7181 measures just 1.00” x 1.75” x 0.260”, providing excellent performance in a compact package. Its insertion loss is less than 0.90 dB, VSWR is less than 1.40:1, isolation is greater than 15 dB, and phase balance is +/- 6 degrees. From 125 – 1000 MHz, its amplitude balance is +/- 1.0 dB, and +/- 2.0 dB at 80 MHz. The IPP-7181 can be used in a variety of applications ranging from VHF to UHF, including radio communications, broadcasting, radar, military, and medical applications.


IPP-7181 Specifications

Amplitude Balance: 1.0 from 125-1000 MHz, 2.0 at 80 MHz
Frequency (MHz):     80–1000
Insertion Loss:           0.9
Isolation:                     15
Package Size:             1.00 x 1.75
Phase Balance:           6
Power:                          250
VSWR Max:                  1.40:1
Export Classification:  EAR99

Amplitude Balance: 1.0 from 125-1000 MHz, 2.0 at 80 MHz
Frequency (MHz):80–1000
Insertion Loss:0.9
Isolation:15
Package Size:1.00 x 1.75
Phase Balance:6
Power:250
VSWR Max:1.40:1
Export Classification:EAR99

As a leading distributor in the UK and Ireland for IPP, APC's expert technical team provides customers with insight and guidance on a wide range of RF and Microwave solutions. Partnering with IPP, our team can advise on their extensive portfolio of broadband, high power couplers, combiners, RF power resistors and terminations operating up to 12 GHz. With our extensive technical expertise and commitment to customer service, we provide tailored solutions to meet your exact requirements.
