MMD-2050LSM

MMD-2050LSM

Marki Microwave

GaAs MMIC Millimeter Wave Doubler

The MMD-2050LSM is a MMIC millimeter wave doubler fabricated with GaAs Schottky diodes. This operates over a guaranteed 10 to 25 GHz input frequency range or a doubled output frequency range of 20 to 50 GHz. It features excellent conversion loss, superior isolations, and high harmonic suppressions across a broad bandwidth.

Both surface mount QFN and evaluation boards are available.

Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

Download The Marki Microwave Product Brochure

View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.

More Information
Attribute Value
RoHS Y
Key Features
  • Low input drive
  • High fundamental rejection
  • Millimeter wave output frequencies
  • RoHS Compliant
Applications
  • High frequency synthesis
  • LO signal chain
Conversion Loss (dB) 12.5
Minimum Input (GHz) 10
Maximum Input (GHz) 25
Minimum Output (GHz) 20
Suppression F (dBc) 35
Suppression 3F (dBc) 46
Maximum Output (GHz) 50
More Information
Attribute Value
Data Sheet Click here to view
