MR9321-01

MR9321-01

Hioki

Logic Probe

Detect AC/DC voltage with Memory HiCorders

Key Features

  • 4 isolated channels
  • ON/OFF detection of 100 V/200 V AC voltage, or 24 V DC
  • Detect of voltage interruptions on power line
  • High speed response of rise time of 1 ms, fall time of 3 ms
  • Connect to a Memory HiCorder with miniature terminal
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Function

Detection of AC or DC relay drive signal for High/Low state recording
Can also be used for power line interruption detection

Dimensions and Weight 62 mm (2.44 in)W × 128 mm (5.04 in)H × 20 mm (0.79 in)D, MR9321-01: 300 g (10.6 oz), MR9321: 320 g (11.3 oz), Main unit cable 1.5 m (4.92 ft), input section cable 1 m (3.28 ft)
Included Accessories Carrying case ×1, Instruction Manual ×1
Max Allowable Input 250 Vrms (HIGH range), 150 Vrms (LOW range) (the maximum voltage that can be applied across input pins without damage)
Output Detection

(H)
170 to 250 V AC, ±DC 70 to 250 V (HIGH range)
60 to 150 V AC, ±DC 20 to 150 V (LOW range)

(L)
0 to 30 V AC, ±DC 0 to 43 V (HIGH range)
0 to 10 V AC, ±DC 0 to 15 V (LOW range)

Response Time Rising edge 1 ms max., falling edge 3 ms max. (with HIGH range at 200 V DC, LOW range at 100 V DC)
More Information
Attribute Value
Data Sheet Click here to view
